21 1/2" x 9 1/4" Ceramic Glass for Gibraltar Stove Applications
Overview:
Replace damaged or broken stove glass with this custom-cut ceramic replacement glass for Gibraltar stove applications. The panel measures 21 1/2" wide by 9 1/4" high and is 3/16" thick. It features a subtle amber tint and is manufactured to withstand temperatures up to 1250°F.
Ceramic glass is designed to handle the extreme temperature changes and thermal shock encountered in high-heat stove applications. This glass may be used for wood, coal, and pellet stove applications when the dimensions and glass requirements match the appliance.
Key Features:
- Custom-cut ceramic replacement glass for Gibraltar stove applications
- Measures 21 1/2" wide x 9 1/4" high
- 3/16" glass thickness
- Withstands temperatures up to 1250°F
- Subtle amber tint
- Designed to resist thermal shock and extreme temperature changes
- Suitable for wood, coal, and pellet stove applications when the appliance requires this type and size of ceramic glass
Important Information:
Proper clearance and installation are essential. Allow at least 1/8" of room for thermal expansion around the replacement glass. Insufficient clearance may cause the glass to expand against surrounding components and break.
Mounting hardware also expands as it heats. Do not overtighten screws, clips, or other retaining hardware against the glass.
Ceramic glass should not be substituted for tempered glass in a fireplace door unless the appliance manufacturer specifically approves ceramic glass for that application. Never install ceramic glass in a factory-built or prefab fireplace unless the unit is heater-rated and the appliance requirements permit its use. Always consult the appliance owner's manual before replacing the original glass type.
FAQs:
Q: What size is this Gibraltar replacement glass?
A: The glass measures 21 1/2" wide by 9 1/4" high and is 3/16" thick.
Q: What type of glass is this?
A: This is ceramic glass designed for high-temperature stove applications.
Q: Can this glass be used in wood, coal, or pellet stoves?
A: Yes, when the appliance requires ceramic glass with these dimensions and specifications. Confirm your appliance requirements before ordering or installing.
Q: How much room should be left for thermal expansion?
A: Allow at least 1/8" of clearance so the glass has room to expand when heated.
Q: Should the mounting hardware be tightened firmly against the glass?
A: No. Do not overtighten screws, clips, or other mounting hardware because the hardware expands when exposed to high temperatures.
Q: Can I replace tempered fireplace-door glass with this ceramic glass?
A: Do not substitute ceramic glass for tempered glass unless the appliance manufacturer specifically approves ceramic glass for that application.
Fit / Measuring / Safety Notes:
- Verify the required width, height, thickness, and glass type before ordering.
- Confirm that 21 1/2" x 9 1/4" x 3/16" matches the glass required for your appliance.
- Allow at least 1/8" of clearance for thermal expansion.
- Do not force an oversized glass panel into the opening.
- Do not overtighten mounting screws, clips, or retaining hardware.
- Check the condition of the glass gasket and related sealing components during replacement.
- Follow the appliance manufacturer's installation and safety instructions.
- Do not replace tempered fireplace-door glass with ceramic glass unless specifically approved by the appliance manufacturer.
- Do not install ceramic glass in a factory-built or prefab fireplace unless the unit is heater-rated and approved for this type of glass.
- Do not operate the appliance if the replacement glass is improperly fitted, unsupported, or damaged.
Helpful Links:
- Browse All Gibraltar Replacement Glass Options for Additional Stove Glass Applications
- Shop Stove Door Gaskets and Related Replacement Parts for Routine Stove Maintenance
- How to Replace Glass on a Wood Stove: Step-by-Step Guide
- Caring for Your Wood Stove: Essential Steps for Safe and Efficient Operation
- Contact Us for Help with Replacement Glass Measurements, Fit Questions, or Product Selection
Product Details / Specifications:
- Brand/Application: Gibraltar
- Application: Replacement stove glass
- Glass Type: Ceramic
- Width: 21 1/2"
- Height: 9 1/4"
- Thickness: 3/16"
- Temperature Resistance: Up to 1250°F
- Glass Tint: Subtle amber
- Intended Applications: Wood, coal, and pellet stoves when glass type and dimensions match
- Thermal Expansion Clearance: At least 1/8"
Fits Stove Models:
- Gibraltar
Manufacturer Warranty:
Fast Replacement Glass provides pyroceram ceramic glass to our customers based on specific size requirements. We warrant to our immediate customers that the glass product ordered will meet certain standards and will be free from material and workmanship defects on the day of shipment.
Fast Replacement Glass does not offer warranties on performance or customer use of the glass. How a customer handles, installs, and uses processes the glass product is solely the customer's responsibility. Fast Replacement Glass cannot be held liable for breakage, damage, or failure of the product due to wrongful installation or if the glass pane is too tight and doesn't allow for thermal expansion during operation of the heating appliance.
Estimated Lead Time
Orders typically leave our warehouse within 2–3 business days. After your order ships, delivery time will depend on your location and the carrier's transit schedule.
Processing and shipping times may vary based on product availability and carrier service. If you have any questions about current stock or estimated delivery dates, please contact us before placing your order.
